Constructions for solar power plants

Reliable solar systems: A key safety factor for solar power plants

Reliable constructions for solar systems not only ensure stability and durability, but also maximum utilization of solar energy, even in difficult weather conditions.

Unpredictable climate changes bring increasingly extreme weather conditions. In such an environment, the key safety factor for solar power plants becomes the resistance of structures to various challenges, such as strong storms, hail, or extreme temperatures, which can result in large unforeseen costs.

Quality materials and innovative designs allow solar power plants to operate safely and efficiently, reducing the risk of damage.

Guarantee on static calculations

A team of engineers for the development of the project

Continuous support during the project

Own production facility

Guarantee on galvanized elements

Exceptional strength and durability: Steel is known for its high strength and durability, making it suitable for supporting large and heavy solar systems. It provides exceptional load capacity and can withstand harsh weather conditions, including high winds and heavy snow loads compared to other lighter structures.
Precise design with static calculations: A team of engineers is dedicated to the development of project plans, which include static calculations, taking into account the specific characteristics of the terrain. By correctly choosing the angle of placing the panels, we optimize the use of solar energy, which significantly increases the efficiency of the system.
Support during the project: In order to provide a complete service, our engineers are available during the entire duration of the project for all questions and support. Whether it’s the design phase, installation or post-sales support, our team is here to ensure a smooth and efficient workflow and provide expert assistance at all times.
Warranty up to 25 years: Steel galvanized systems according to the EN 1461 standard come with a warranty of up to 25 years, depending on the conditions of the corrosive environment. These long-term guarantees provide security and stability of the investment, making it a reliable choice for the long term.

Constructions for solar power plants - rebuttal

Precast constructions are ideal for installations in areas where it is possible to simply place posts in the ground.

This system enables quick and easy installation, with minimal construction work.

They provide stability and resistance to different weather conditions, making them the perfect solution for outdoor solar panels.

Landscape Modul

technical specifications

Layout of the module	Landscape
by row	1
Angle	10, 15, 20, 25, 30
Depth of rebuttal	1400 mm
Material	high-quality construction steel with increased durability
Additional options	inverter assembly set

Portrait Modul

technical specifications

Layout of the module	Portrait
by row	1
Angle	10, 15, 20, 25, 30
Depth of rebuttal	1300 mm
Material	high-quality construction steel with increased durability
Additional options	inverter assembly set

Constructions for solar power plants - anchoring

Anchored structures offer additional security in areas with more demanding conditions, such as windy terrain or areas with difficult soil conditions.

This system uses solid foundations that ensure the longevity and stability of solar installations, reducing the risk of movement or damage.

Landscape Modul

technical specifications

Layout of the module	Landscape
by row	10 in row (2 columns by 10 row)
Angle	10, 15, 20, 25, 30
Depth of rebuttal	Anchoring
Materijal	high-quality construction steel with increased durability
Additional options	inverter assembly set

Portrait Modul

technical specifications

Layout of the module	Portrait
by row	10 in row (2 columns by 10 row)
Angle	10, 15, 20, 25, 30
Depth of rebuttal	Anchoring
Materijal	high-quality construction steel with increased durability
Additional options	inverter assembly set
